Rcf 12135058 AM 2160 - 4+2 input mixer amplifier

COMMERCIAL AUDIO AM 2160 MIXER AMPLIFIER Full digital technology Mixer Amplifier with 160 W RMS power. Supports 100 V, 70 V, and 4 Ohm outputs. Features 4 universal inputs with phantom power, presence control, and per-channel high-pass filters. Features Full digital technology Mixer Amplifier with 160 W RMS output. Compatible with 100 V, 70 V, and 4 Ohm systems. Four universal inputs with phantom power on screw terminal connections. Presence control and per-channel high-pass filters. XLR connector on input 1. RJ45 connectors on inputs 2 and 3 for connection to BM3001 microphone. Configurable priority settings with VOX functionality on input 1. Selectable auxiliary inputs controlled via front panel keys for music sources. Auxiliary inputs include volume and tone controls. Music On Hold and PRE outputs. Designed with 4 mic-line inputs (including XLR on input 1) and 2 aux inputs for music sources like CD players and tuners. 160 W nominal power for low impedance or constant voltage line systems. Part Number 12135058 AM 2160 EAN: 8024530006396 Specifications Amplifier Specifications Amplifier Class: D Output Power: 1 x 160 W @ 4 Ohm Frequency Response (-3dB): 50 Hz ÷ 14 kHz Distortion (THD+N) @ 1 kHz Nominal Power: <0.3% Input Section Total Number of Inputs: 8 Balanced Inputs: 7 Unbalanced Inputs: 2 Mono Inputs: 7 Stereo Inputs: 2 Line Inputs: 2 (RCA connectors) Mic+Line Inputs: 4 (Euroblock, XLR connectors) Mic+Line Phantom Power: 32 V DC VOX Functionality: Yes Paging Inputs: 2 (RJ45 connectors) Paging Command: Contact General Purpose Inputs (GPI): 2 Output Section Signal Output Number: 2 Signal Output Connectors: RCA Power Output Connectors: Euroblock Processing Tone Controls: Yes High-Pass Filter: 150 Hz Configuration and Control Configuration Options: DIP switch, Front panel Priority Settings: Yes Music On Hold: Yes Chime Tone: Yes Protections Cooling: Convection Short Circuit Protection: Yes Thermal Protection: Yes DC Protection: Yes Fuses: Yes Power Requirements Operating Voltage: 220-240/115 V~ 50/60 Hz Voltage Selection: Internal Power Consumption (MAX): 350 Wa Standard Compliance Safety Agency: CE compliant Physical Specifications Material: Metal Color: Black Rack Mounting: 19", 2U Height: 88 mm / 3.46 inches Width: 442 mm / 17.4 inches Depth: 230 mm / 9.06 inches Weight: 5.4 kg / 11.9 lbs Shipping Information Package Height: 200 mm / 7.87 inches Package Width: 500 mm / 19.69 inches Package Depth: 330 mm / 12.99 inches Package Weight: 6.45 kg / 14.22 lbs
